BLE 2.45GHz Active RFID Long Range Rugged Tag/Beacon
BLE 2.45GHz Active RFID Long Range Rugged Tag/Beacon
Description
Overview:
GAORFID SKU#127030 long reading range and rugged beacon/tag operates at 2.45GHz, the SKU#127030 tag is a new generation beacon that is loaded with Bluetooth 5.0 hardware platform, and supports to advertise standard iBeacon. SKU#127030 long range beacon tag combines standard iBeacon, Eddystone (UID, URL, TLM). The super-long reading distance feature (up to 300 meters) and over 10 years battery lifetime make it an ideal solution for shopping malls, airports and railway applications.
Main Features:
- Standard iBeacon, free band of 2.45GHz
- Bluetooth® 5.0 chipset nRF52 series
- The max. 300 meters reading distance with SKU#217020 gate way or any other Bluetooth Featured devices (e.g. iPhones, Android smart devices, etc.)
- IP66 Water/Dust proof and Shock resistance capabilities
- Battery Replace-able
Applications:
- BLE sensor reader / receiver
- Asset tracking
- Access control management
- Indoor location and position
- IoT related
- Active RFID
- Railway
Technical Specifications:
| Size/Weight | 72*72*18mm/ 110g |
| Bluetooth | Bluetooth low energy 5.0 |
| Frequency | 2.45GHz |
| Beaconing Interval | Software Configurable 100ms to 5000mS |
| Transmit power | -40dBm ~ +4dBm |
| Reading Distance | Up to 300 meters (in open space) |
| Operating / Storage temperature | -20°C to 70°C / -25°C to 65°C |
| Humidity | Max 95%, Non condensing, relative humidity |
| Battery Life | Replace-able AA 2900mAh batteries, over 10 years life span |
| Mounting Method | Double-sided adhesive |
