I-Code SLIX High Frequency RFID Sleeve Tag
I-Code SLIX High Frequency RFID Sleeve Tag
Description
Key Features
- PA6 (Nylon) housing
- Good thermal inertia protect
- Perfect protection against impact shock, pressure and other mechanical stresses.
- UV resistance
- Severe mechanical, thermal and chemical stresses environments and outdoor applications such as offshore platforms
Technical Specifications
| Frequency | I-Code SLIX (HF) |
| IC Type | I-Code SLIX |
| Material | PA6 (Nylon) |
| Mounting | Using standard plastic or metal cable binders |
| Electrical | · Electrostatic discharge– ESD: ±5kV, 2 times
· Reading distance: depends on environmental condition, chip type and reader |
| Thermal | · Operational: -40°C to +85°C
· Storage: -40°C to +90°C (1000h) · Peak: +140°C (10h), +130°C (100h) · Temperature shock: -40°C, +90°C, 5min. soaking time, 30sec. transition, 100cycles |
| Physical | · Shock, IEC 68.2.29: Sin-half-wave, 30g, 18ms, 1100 each direction, +X, -X, +Y, -Y, +Z, -Z
· Vibration IEC 68.2.6: Sinusoidal, 6g, 10-200Hz, linear, 1Hz/sec., 8h per axis, X,Y,Z · IP rating: IP68, 1m/24h · Surface Color: Black, yellow, red, green, blue · Dimensions: 27 mm x 20.5 mm |
| Chemical
and environmental resistance |
· Aqueous solution of salts, alcohol, hydrochloric acid (10%), fuel B, 25% ammonium chloride.
· Humidity 90% r.H. @ 90°C, 100h |
| Qualification | All test done at room temperature if not defined different |
| Options | Laser engraving, customized insert, optional EMI foil for mount on metal |
| Weight | 5±1 g |
| Packaging | 100 pcs / box (Box size: 210x100x60 mm) |
