LF & HF, 125 KHz & 13.56 MHz Waterproof Wristband RFID Tag
LF & HF, 125 KHz & 13.56 MHz Waterproof Wristband RFID Tag
Description
Overview
The RFID wristband functions on 125 KHz and 13.56 MHz frequencies and compatible to ISO 15693 & ISO 14443 standards. It consists of EMS memory which can be wiped and written up to 10k times. The tag is ideal in water environment such as Water Park, cruise, swimming pool. Furthermore, data maintenance period is around 10 years which shows robustness of the wristband. It is available in large range of colors and can be customized with company’s logo. An attractive wristband makes tag looks like ordinary bracelet rather than an RFID tag.
Key Features
- ISO15693 & ISO 14443 standards compliant
- Easy to wear, flexible and waterproof
- Erase and write up to 1,00,000 times
- Data retention till 10 years
- Customized with various colors and logo
Applications
- Wet places like water park, cruise, swimming pool control applications
- Access control systems
- People tracking application
Technical Specifications
| RF Specifications | |||
| RF Air Protocols | ISO 15693 & ISO 14443 | ||
| Operating Frequency | 125 KHz & 13.56 MHz | ||
| Read/ Write Cycles | Up to 1,00,000 times | ||
| Read distance | Up to 0.33 ft. (10 cm) | ||
| Mechanical Specifications | |||
| Material | Plastic | ||
| Dimension | Diameter | 1.26 in x 1.65 in x 0.31 in (32 mm x 42 mm x 8 mm) | 2.12 in (54 mm) |
| Environmental Specifications | |||
| Operating Temperature | -40 °F to 158 °F (-40 °C to 70 °C) | ||
