On Metal UHF EPC Gen 2 RFID Tags
On Metal UHF EPC Gen 2 RFID Tags
Description
Features
- A small-sized global RFID tag with high performance satisfying the diverse needs of logistics industries
- Applicable for attachment to metal bars commonly found on RTI’s
- This product is compliant with standards that it is approved by RoHS and CE, and also with options of certified by ATEX/IECEx and US & Canada (C1D1/D2)
- Allows attachment through mechanical assembly (standard), film adhesive (option without holes) and foam adhesive (option without holes)
- The frequency range of 860-930 MHz
- It provides a long read range of up to 19.7 ft. (6.0 m) for fixed reader and 9.8ft (3.0m) for handheld reader
- Equipped with a memory of 96 bits (EPC), 512 bits (User), 64 bits (TID)
- Broad read angle
- Provides adhesive or rivet hole mounting options
- Compatible with metal and non-metal (Optimized for metal)
- An IP rating of IP68
- Shock and vibration resistance verified through MIL-STD 810-F
- Used Impinj Monza4QT™ as an IC model
Applications
- Used for RTI applications in industries such as Logistics and Postal, Automotive, Retail and Warehousing
Technical Specifications
| Operating Temperature | -40 °F to 185 °F (-40 °C to 85 °C) |
| Frequency Range | 860 to 930 MHz |
| Maximum Read Range | Fixed reader: Up to 19.7 ft. (6.0 m)
Handheld reader: Up to 9.8 ft. (3.0 m) |
| Material Compatibility | Metal and Non-Metal (Optimized for metal) |
| IC Type (chip) | Impinj Monza 4QT |
| Tag Materials | ABS Rigid Plastic |
| Dimensions | With holes: 3.15 × 0.59 × 0.48 in (80 × 15 × 12.2 mm)
Without holes: 2.36 × 0.59 × 0.48 in (60 × 15 × 12.2 mm) |
| Memory | EPC: 96 bits*
Use: 512 bits* TID: 64 bits *Reprogrammable memory |
| IP Rating | IP68 |
| Attachment Method | Mechanical (standard)
Film adhesive (option without holes) Foam adhesive (option without holes) |
| Air Interface Protocol | EPC global UHF Class 1 Gen2 (ISO 18000-6C) |
| Weight | With holes: 0.028 lbs. (12.5 g)
Without holes: 0.025 lbs. (11.5 g) |
| Long Term Max Temperature Exposure | 185 °F (85 °C) |
| Short Term Max Temperature Exposure | 221 °F (105 °C) |
| Halt Thermal Cycling -4 °F to 185 °F (-20 °C to 85 °C) exposure time |
50 cycles |
| Impact | 22.05 lbs. (10 kg) from 3.28 ft. (1 m) |
| Shock and Vibration Resistance | MIL-STD 810-F |
| EPC Memory Content | Unique, randomized number |
| Tag Form Factor | Hard tag |
| Certifications | RoHS approved
CE approved ATEX/IECEx certified (option) US & Canada (C1D1/D2) certified (option) |
| Warranty | 3 years |
